DALY battery management system Pack liion 6S 24v parallel BMS 5A

  1. Prevent PACKs from being recharged with large currents due to differences in internal resistance and voltage when they are connected in parallel.
  2. In case of parallel connection, different pressure difference causes charge between battery packs.
  3. Limit the rated charging current, effectively protect the high current protection board and battery.
  4. Anti-sparking design, the battery pack connected in parallel with 15A will not cause sparking.
  5. Current limiting indicator light, when the trigger current limiting is turned on, the indicator light on the paralel protector is lit

Product Detail

Product Tags

DALY PACK Parallel BMS

Pack Parallel Module+BMS=Pack Parallel BMS
Realize safe parallel connection of lithium battery pack.Suitable for Li-ion 3S/LifePo4 4S/30A-60A BMS, and 5A PACK Parallel BMS.

daply1
daply2

More power in safe parallel

Active balancing technology allows the same type of lithium battery packs with the same number of series to safely connect more power in parallel.

daply3

Avoid high current shock

 Limit the Max charging current, effectively prevent high-voltage battery pack charge to low-voltage battery pack by high current shocks.

daply5

Bluetooth Smart Communication

Connect the BMS through the mobile phone Blue-tooth APP, monitor the battery data in real time, and set the relevant parameter values (monomer voltage, total voltage, temperature, power, alarm information, charge and discharge switch, etc.).

daply6

Intelligent Control Of Parallel Battery Packs

Through communication protocol and external components, the running data of parallel battery pack can be presented to the display device in real time, and related parameters can be viewed or set.

daply7

Precharge Resistor Optimized Power-on Sequence

BMS is equipped with a precharge resistor to pr-event the power-on current from being too large and short-circuit, and prevent the BMS from being damaged by the super capacitor.

daply8

Unique TVS

Prevent high pressure shock
The unique TVS realizes faster over-voltage protection, effectively clamps the surge voltage, prevents reverse voltage from impacting the MOS, and makes the overall performance of the BMS reliable and strong.

daply9

Advantages Of Parallel Lithium Battery Pack

daply10

Selected High-quality Parts

Behind every inconspicuous detail, there is quality ingenuity, and the texture can be seen everywhere.

daply11

Wide application field

DALY PACK parallel BMS has powerful functions. Suitable for various lithium battery application scenarios in power, energy storage and other fields.

daply12

Product Specification

 Easily select for parallel module.

9

Product Parameters

PACK parallel BMS parameters list

img (1)

PACK Parallel BMS dimensions table

img (2)

PACK parallel BMS wiring diagram

Please select the corresponding wiring method according to the purchased model.
Wiring method of 1A parallel module.
The 1A parallel protector has only one wire outlet, and there are 5 wires in total. It is only necessary to combine the 5 wires and connect them to the corresponding DO port of the BMS.

10

PACK parallel battery pack wiring diagram

1.PACK parallel protective board consists of two parts:
The BMS+parallel protector,that is,each PACK that needs parallel. The two must be included.
2.The detailed wiring method of the protective board view the wiring map of the protective board.
3.Wiring Precautions
Method 1
(the BMS and the parallel BMS module wire are not connected):After the BMS is assembled, when the parallel BMS module is connected to the BMS, first connect the parallel BMS modules P-wire to the BMS (the common port is connected to the BMS P-wire, and the separate port is connected to the BMS C- wire), and then connect B-and B+ in turn.After the wire is connected,first plug the BMS and parallel BMS module ports, then the B+ port, and plug the control signal wire to the protection board finally
Method 2
(BMS and parallel BMS module lines are connected): first plug the BMS and parallel BMS module ports, then plug into the B+ port, and finally plug into the control signal line to the BMS;
※Please strictly follow the above two methods for wiring, please operate in sequence if the wiring sequence is reversing, it will cause damage to the parallel BMS module.
4.The BMS and parallel BMS modules must be used together and can't be mixed using. Wiring should be done according to the purc-hased parallel BMS module corresponding to the current.
Corporate Mission
Innovate intelligent technology and create the green energy world.

Dongguan DALY Electronics Co., Ltd. is an innovative enterprise specializing in Battery Management System. It pursues the principle of "respect, brand, common goal, achievement sharing", with the mission of innovating intelligent technology and creating and enjoying the green energy world, and with the vision of becoming the world's leading new energy company driven by technology.

Innovation-driven and technology-leading

With technology as the driving force, DALY BMS has established DALY-IPD integrating product R&D management system, and obtained nearly 100 patents, such as Plastic Injection for waterproof and High Thermal Conductivity Control Board.

Strong production capacity and various products

DALY has promoted standard BMS, smart BMS, parallel module, active balancer etc. which can meet the application needs of various lithium batteries in power, energy storage and other fields. The personalized customization of BMS can be fulfilled in DALY BMS.

daply18

Professional Technical Support

A strong team of 100 engineers to provides professional one-to-one technical support and services. Standard questions will solve within 24h to provide customers with considerate service.

daply4

Strong Production Capacity Annual output of various types of BMS more than 10 million.

Purchase Notes

daply19

DALY company engaged in R&D, design, production, processing, sales and after-sales maintenance of Standard and smart BMS, professional manufacturers with complete industrial chain, strong technical accumulation and outstanding brand reputation, focusing on create "more advanced BMS", strictly carry out quality inspection on each product, obtain the recognition from customers around the world.
Please view and confirm the product parameters and details page information carefully before purchasing, contact with online customer service if have any doubts and questions. To make sure you are buying the correct and suitable product for your use.

Return and exchange instructions

1.Firstly, Please carefully check whether it is consistent with the ordered BMS after receiving the goods.
2.Please operate in strict accordance with the instruction manual and the guidance of customer service personnel when installing the BMS. If the BMS does not work or is damaged due to misoperation without following the instructions and customer service instructions, customer need to pay for repair or replacement.
3.please contact customer service personnel if have any questions.

Delivery Notes

1.Ships within three days when in stock(Except holidays).
2.Immediate production and customization are subject to consultation with customer service.
3.Shipping options: Alibaba online shipping and customer's choice(FEDEX, UPS,DHL,DDP or economic channels..)

Warranty

Product warranty: 1 year.
